Glovebox
Glovebox
Glovebox Feature
Glovebox Detail

Please note: Specification may vary depending on configuration

Glovebox sizes

  • 1200mm (W) x 780mm (D) x 920mm (H)
  • 1450mm (W) x 780mm (D) x 920mm (H)
  • 1950mm (W) x 780mm (D) x 920mm (H)

Glovebox Specification

  • Stainless steel 1.4301 (US Type 304) construction
  • High vacuum, KF 40 inserts 220V Power (24V optional)
  • Circulation system: air inlet and outlet all with  HEPA  filter
  • Scratch resistant polycarbonate or tempered glass window
  • 0.4mm Glovebox gloves (optional glove sizes and material are available)
  •  Aluminium alloy or POM 220mm diameter glove ports
  • Fluorescent front mounted lamp
  • Adjustable stainless steel shelving (1000mm (W) x 220mm (D))
  • Leak rate <0.05 vol%/h (acc. ISO 10648-2)
  • Weight 400/550 kg

Large Antechamber Specification

  • Cylindrical design w/ stainless steel sliding tray
  • Antechamber size 390mm diameter x 600mm length
  • Stainless steel 1.4301 (US Type 304) construction
  • Aluminum doors opening in vertical direction (gas piston)
  • Manual vacuum operation (optional automatic available)
  • Leak rate <10-5 mbar l/s (Class 1)

GP20 Compact Gas Purification Specification

  • Single column gas purifier unit
  • Attainable purity level H2O < 1 ppm, O2 < 1 ppm
  • Removal capacity 20L O2 , 1000g H2O
  • Rotary vane pump w/ a displacement equal to 17m3h @ 60 Hz
  • Electro-pneumatic valves
  • Auto regeneration
  • Variable speed blower
  • Stainless steel 1.4301 (US Type 304) piping
  • Flow rate 20 m3/h at ΔP= 60 mbar
  • 230 V/50-60 Hz, 10 A or 115 V / 50-60 Hz, 20 A or 100 V/ 50-60 Hz, 20 A

Controller Specification

  • Micro-controller with operation panel (touch panel display optional)
  • Automatic box pressure control / foot switch (+15 mbar, -15 mbar)
